Water Jet Pumps

Water jet pump

  • nickel plated brass
  • non-return valve
  • connector plug
Article no.ThreadWeight
5751G 1/2188 g
  • Technical data
    Item no. Max. vacuum
    bar”    		 Seconds until max. vacuum Consumption in l/min Max. suction capacity in l/h Water pressure in bar Non-return valve Threaded connection Connection plug Weight in g
    5751 -0.9 6 6.4 185 4 + G 1/2 188
    Item no. Max. vacuum in bar Seconds until max. vacuum Consumption in l/min Max. suction capacity in l/h Water pressure in bar
    5751 -0.9 6 6.4 185 4
    (Table continued)
    Item no. Non-return valve Threaded connection Connection plug Weight in g
    5751 + G 1/2 188
    at a water temperature of 10° C*
    Valve ball from NBR 67/60, chemical resistance according to special list
