Bunsen burner needle valve

air regulation
needle valve

Article no.	Gas
1010	Natural gas
1011	Bottle gas

DIN version
DIN-DVGW reg. no.NG-2211AN0133

Article no.	Gas
1010/1	Natural gas
1011/1	Bottle gas

Burners according to DIN 30665 cannot be switched off completely. A small flame remains burning even if needle valve or stop cock are turned off. The gas flow shall be disconnected by means of the central stop cock in the laboratory.

Learn more about our laboratory burners here.

The picture shows the burner with safety base (extra charge)

Operating manual (PDF) Certificate (PDF)

Technical data

Item no.	Natural gas	Propane gas	DIN	Temp. °C	Consumption in l/h	Load in kW	Weight in g	Height in mm	Pipe ø in mm	Head ø in mm	Safety base available
1010	+			1500	110	1,00	220	155	14	17	o
1011		+		1550	55	1,70	220	155	14	17	o
1010/1	+		+	1500	115	1,00	220	155	14	17	o
1011/1		+	+	1550	55	1,70	220	155	14	17	o

Item no.	Natural gas	Propane gas	DIN	Temp. °C	Consumption in l/h	Load in kW
1010	+			1500	110	1,00
1011		+		1550	55	1,70
1010/1	+		+	1500	115	1,00
1011/1		+	+	1550	55	1,70

(Table continued)

Item no.	Weight in g	Height in mm	Pipe ø in mm	Head ø in mm	Safety base available
1010	220	155	14	17	o
1011	220	155	14	17	o
1010/1	220	155	14	17	o
1011/1	220	155	14	17	o
